| Sistem de operare |
|---|
| OS | Android 15 (upgradable to A17) |
|---|
| GMS certified | GMS certified |
|---|
| CPU | Octa-core 2.2GHz Processor |
|---|
| Memory | RAM 6GB; Flash 64GB |
|---|
| Languages support | English, Simplified Chinese, Traditional Chinese, Japanese, Spanish, German, French, Italian, Portuguese, Korean and; multiple languages |
|---|
| Others | Input Chinese/ English; Supports handwriting and soft keyboard |
|---|
| Ecran |
|---|
| Screen Size | 6”, HD+ (720x1440) color screen, backlight 500nits |
|---|
| Touch Panel | Multi-Touch Capacitive Touch Panel, support stylus, glove, wet-finger Compatibility |
|---|
| Butoane / tastatură |
|---|
| Buttons / Keypad | 6 keys- Programmable function button; dual dedicated scan buttons; volume up & down buttons; on/off button |
|---|
| Cameră |
|---|
| Camera | 8MP front camera; 16M rear camera with auto-focus function and Flash Light |
|---|
| Indicatori |
|---|
| Type | LED, Speaker, Vibrator |
|---|
| Simbologii |
|---|
| 1D Barcodes | UPC/EAN, GS1-128 , Code128, Code 39, Code 93, , Code 11, Interleaved 2 of 5, Matrix 2 of 5, Codabar, MSI, GS1 DataBar |
|---|
| 2D Barcodes | PDF417, MicroPDF417, Data Matrix, MaxiCode, QR Code, Micro QR Code, Aztec, Han Xin, GS1 Composite |
|---|
| Postal | US Postnet, US Planet, UK Postal, Japanese Postal, Australian Postal, Netherlands (KIX)/ Dutch Postal, USPS 4CB/ One Code/ Intelligent Mail/ UPU FICS Postal |
|---|
| OCR | OCR-A, OCR-B, E13B (MICR) |
|---|
| RFID |
|---|
| UHF RFID | (option) Up to 1.8m; 865~868MHz (EU), 902~928MHz (US) |
|---|
| HF RFID | Frequency 13.56MHz, support NFC(Power:1dBm); Compliance w/ ISO14443A/B, ISO15693, Mifare, Felica(ISO/IEC18092) |
|---|
| Interfețe I/O |
|---|
| USB | USB 2.0 (type-C) |
|---|
| OTG | Yes, over USB Type-C |
|---|
| POGO PIN | PogoPin backside: Support Gun-grip; PogoPin bottom: Charging via cradle |
|---|
| SIM Slot | 1 eSIM +1 nano SIM |
|---|
| Expansion Slot | MicroSD, up to 1TB |
|---|
| Audio | One speaker (95dB @ 10cm), One receiver, Dual noise-cancelling microphones |
|---|
| Alimentare |
|---|
| Main battery | Warm Swappable 4250mAh Li-Polymer battery* / battery with cover in one piece;; *Warm-swappable battery is supported on standard 4G and Wi-Fi models only.; The UHF model does not support warm swap. |
|---|
| Comunicații |
|---|
| Bluetooth® | Bluetooth® 5.2, BLE |
|---|
| WLAN | Wi-Fi 6E, 2.4GHz & 5GHz & 6GHz; IEEE 802.11a/b/g/n/ac/d/e/h/i/k/r/u/w/v/ax, Support DBS; Security: WPA3, WPA2, WPA & WEP |
|---|
| WWAN | 4G LTE (FDD): B1/2/3/4/5/7/8/12/17/19/20/28a&b/66; LTE (TDD): B38/39/40/41; 3G WCDMA: B1(2100MHz), B2(1900MHz), B4(1700MHz), B5(850MHz), B8(900MHz); 2G GSM: B2(1900MHz),B3(1800MHz), B5(850MHz), B8(900MHz) |
|---|
| GPS | GPS, Beidou, Glonass, Galileo, A-GPS |
|---|
| Sensors | Gyroscope, G-sensor, E-compass, Light & Proximity Sensor |
|---|
| Software |
|---|
| MDM Software | SOTI, VMware, MoboLink and TagAccess |
|---|
| Carcasă |
|---|
| Dimensions ( W x H x D ) | 161mm x 76.8mm x 14.15mm |
|---|
| Weight | 242g ± 1% (with battery) |
|---|
| Rezistență |
|---|
| Drop Specification | 1.5m, 1.8m with boot case |
|---|
| Sealing | IP65 & IP68 |
|---|
| Tumble test | 0.5m tumbles for 300 cycles / 600 drops |
|---|
| Condiții de mediu |
|---|
| Operating temperature | -20°C to 50°C |
|---|
| Storage temperature | -30°C to 70°C (without battery) |
|---|
| Charging temperature | 0°C to 45°C |
|---|
| Relative Humidity | 5% ~ 95% (Non-Condensing) |
|---|
| Accesorii |
|---|
| Accessories | ■ Battery 3.85V 4250mAh (PN#1400-900081G); ■ USB 3.0 type-C cable(Support Quick Charge) (PN#1550-905908G); ■ Quick charge adaptor via USB type-C cable (PN#1010-900073G US plug/ #1010-900074G EU plug); ■ Glass Screen Protector w/ packing, 10pcs/ box (PN#5400-900078G); ■ Boot Case (PN#3210-900050G); ■ Hand Strap with fixed arm- individual package (PN#5400-900052G); ■ 1 Fixed Arm, 2 Screws for Hand Strap (PN# 5400-900051G); ■ Stylus (8mm: PN#384896G / 5.5mm: PN#386534G); ■ Coiled Strap (PN#387610G); ■ Single Slot Charging Cradle (PN#5000-900129G); ■ Single Slot USB Cradle (PN#5000-900130G); ■ Single Slot Ethernet Cradle (PN#5000-900131G); ■ Docking station (PSU Only) (PN#5000-900142G); ■ 5-slot Terminal Charging Cradle (12V/5A PSU Only) (PN#5000-900132G); ■ 5-Slot Ethernet & Charging Cradle (12V/5A PSU Only) (PN#5000-900134G); ■ 4-Terminal+ 4-Battery Charging Cradle (12V/5A PSU Only) (PN# 5000-900154G); ■ 4-slot battery charger(PSU Only) (PN# 5100-900042G); ■ 12V/5A Power Supply in the Multi-slot Cradle (PN#1010-900068G); ■ 3-Pin Power Cord(US) (PN#1010-601551G); ■ 3-Pin Power Cord(EU) (PN#1550-602333G); ■ 3-Pin Power Cord (UK) (PN#1550-602689G); ■ Gun Grip (PN#5500-900115G); ■ RP902 Bluetooth UHF RFID Pocket Reader; (PN#RP902-33E8S0G(EU),PN#RP902-43A8S0G(US),PN#RP902-43F8S0G (JP)); ■ Soft Belt Holster with Belt Clip (PN#DT3669); ■ Belt Holster (PN#381852); * Use USB Cable & Power Adapter from EA530; ■ Vehicle cradle (PN#5000-66C0001G) |
|---|
| Conținutul pachetului |
|---|
| The standard package contents | ■ EA530 Terminal; ■ USB 3.0 Cable (Type C); ■ Adaptor (US) |
|---|
| The basic package contents | ■ EA530 Terminal; ■ USB 3.0 Cable (Type C) |
|---|
| Certificări |
|---|
| Regulatory Approvals | CE, FCC, NCC, VCCI, TELEC, CCC, SRRC, BQB, N-Mark, RoHS 2.0 |
|---|
| Garanție |
|---|
| Hardware Warranty | 12 months |
|---|
| Statement | This product is warranted against defects in workmanship and materials for a period of twelve months from the date of shipment. Accessories are warranted for three months to one year. Our different regions have varying warranty terms, and offer extended and comprehensive warranties, so please contact your local representative for more information. |
|---|
