| Sistem de operare |
|---|
| OS | Android 15 (upgradable to A17); Support Google ARcore |
|---|
| GMS certified | GMS certified |
|---|
| Android Enterprise | AER certified |
|---|
| CPU | Qualcomm Snapdragon™ 4490 Processor, 64bits, Octa Cores up to 2.4GHz |
|---|
| Memory | 6GB RAM / 8GB RAM (option); Flash 128GB UFS |
|---|
| Security | Supports Secure Boot and Verified Boot |
|---|
| Languages support | English, Simplified Chinese, Traditional Chinese, Japanese,; Spanish, German, French, Italian, Portuguese, Korean and multiple languages |
|---|
| Others | Input Chinese/ English; Supports handwriting and soft keyboard |
|---|
| Ecran |
|---|
| Screen Size | 6", 18:9 Full-HD+ (2160X1080), color screen, High sunlight visibility- LCD backlight up to 630nits |
|---|
| Touch Panel | Corning® Gorilla® Glass Victus®, 5-point capacitive multi-touch, stylus (5.5 mm), glove mode (3 mm), wet-finger compatibility |
|---|
| Butoane / tastatură |
|---|
| Buttons / Keypad | 5 keys- Programmable function button; dual dedicated scan buttons; volume up/down buttons; on/off button |
|---|
| Cameră |
|---|
| Camera | 5 MP Front camera,; 16 MP Rear with auto-focus function and Flash Light |
|---|
| Indicatori |
|---|
| Type | LED, Speaker, Vibrator |
|---|
| Simbologii |
|---|
| 1D Barcodes | UPC/EAN, GS1-128 , Code128, Code 39, Code 93, , Code 11, Interleaved 2 of 5/ITF-14, Matrix 2 of 5, Codabar, MSI, GS1 DataBar |
|---|
| 2D Barcodes | PDF417, MicroPDF417, Data Matrix, MaxiCode, QR Code, Micro QR Code, Aztec, Han Xin, GS1 Composite |
|---|
| Postal | US Postnet, US Planet, UK Postal, Japanese Postal, Australian Postal, Netherlands (KIX)/ Dutch Postal, USPS 4CB/ One Code/ Intelligent Mail/ UPU FICS Postal |
|---|
| OCR | OCR-A, OCR-B, E13B (MICR) |
|---|
| RFID |
|---|
| HF RFID | Support HF/NFC; Frequency 13.56Mhz; Support ISO14443-4 (Type A, Type B), ISO15693, Mifare, Felica(ISO/IEC18092) compliance |
|---|
| Interfețe I/O |
|---|
| USB | USB 3.1 (type-C) support USB OTG, DRP, DRD, Type C; Ethernet/USB-Host via cradle |
|---|
| OTG | Yes, over USB Type-C |
|---|
| POGO PIN | PogoPin backside: Support Gun-grip, UHF reader; PogoPin bottom: Charging via cradle |
|---|
| SIM Slot | 1 eSIM+1 nano SIM |
|---|
| Expansion Slot | MicroSD, up to 1TB |
|---|
| Audio | One speaker ( up to 104 dB @ 4kHz at 10cm), One receiver,; Dual noise-cancelling microphones, Smart PA |
|---|
| Alimentare |
|---|
| Main battery | 3.87V, 5000mAh UL certified smart battery; Support Warm SWAP |
|---|
| Comunicații |
|---|
| Bluetooth® | Bluetooth® 5.2, support BLE |
|---|
| WLAN | Wi-Fi 6E (2.4GHz & 5 GHz & 6 GHz); IEEE 802.11 a/b/g/n/ac/ax/d/e/h/i/k/r/v (MU-MIMO 2X2); Supports Dual Band Simultaneous (DBS) and Fast Roaming (802.11r with PMKID caching); Security WPA3, WPA2, WPA, WEP, EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, Wi-Fi CERTIFIED™ |
|---|
| WWAN | 5G NR: n1, n2, n3, n5, n7, n8, n12, n20, n28, n34, n38, n39, n40, n41, n48, n66, n77, n78, n79; 4G LTE (FDD): B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B19, B20, B28, B66; LTE (TDD): B34, B38, B39, B40, B41, B48; 3G WCDMA/UMTS/HSPA+: B1 (2100MHz), B2 (1900MHz), B4 (1700MHz), B5 (850MHz), B8 (900MHz); 2G GSM/GPRS/EDGE: B2 (PCS1900), B3 (DCS1800), B5 (GSM850), B8 (GSM900); Support Data, SMS and Voice capabilities; *n48& B48 for CBRS |
|---|
| GPS | GPS, GLONASS, Gallileo, BeiDou, QZSS,; supports L1+L5, a-GPS, XTRA |
|---|
| Sensors | Gyroscope,G-sensor, E-Compass,Light & Proximity Sensor |
|---|
| Software |
|---|
| MDM Software | SOTI, VMware and MoboLink |
|---|
| Carcasă |
|---|
| Dimensions ( W x H x D ) | 162.9mm x 77mm x 14.9mm |
|---|
| Weight | 270g ± 1.5% (with battery)*; *The weight will vary depending on the configuration. |
|---|
| Rezistență |
|---|
| Drop Specification | 1.5m drops to concrete per MIL-STD-810H; 1.8m with boot case |
|---|
| Sealing | IP65 & IP68 |
|---|
| Tumble test | 0.5m tumbles for 300 cycles / 600 drops for EA660; 1m tumbles for 500 cycles / 1000 drops for EA660 with boot case |
|---|
| Condiții de mediu |
|---|
| Operating temperature | -20°C to 55°C |
|---|
| Storage temperature | -40°C to 70°C (without battery) |
|---|
| Charging temperature | 0°C to 45°C |
|---|
| Relative Humidity | 5% ~ 95% (Non-Condensing) |
|---|
| Accesorii |
|---|
| Accessories | ■ USB 3.0 type-C cable for terminal & 1-slot cradle (PN#1550-905908G); ■ Quick charge Adaptor with US plug for terminal & 1-slot cradle (PN#1010-900073G); ■ Quick charge Adaptor with EU plug for terminal & 1-slot cradle (PN#1010-900074G); ■ hand strap (PN#5400-900052G); ■ 1 Fixed Arm, 2 Screws for Hand Strap (PN# 5400-900051G); ■ Boot case (PN#3210-900040G); ■ 9H glass screen protector ( PN#5400-900062G, 10pcs with Packing ); ■ Battery 3.87V 5000mAh (PN#1400-900074G); ■ Stylus ( 5.5mm #386534G); ■ Coiled strap (PN# 387610G); ■ Gun grip (PN# 5500-900108G); ■ Wrist Lanyard (PN#385892G); ■ RP902 Bluetooth UHF RFID Pocket Reader (PN# RP902-33E8S0G (EU) / RP902-43A8S0G (US) / RP902-43F8S0G (JP); ■ Single Slot Charging Cradle *(PN#5000-900129G); ■ Single Slot USB Cradle *(PN#5000-900130G); ■ Single Slot Ethernet Cradle *(PN#5000-900131G); * Use USB Cable & Power Adapter from EA660; ■ 5-Slot Terminal Charging Cradle(PSU Only) (PN#5000-900132G); ■ 5-Slot Ethernet Cradle(PSU Only) (PN#5000-900134G); ■ 4-Terminal+ 4-battery Charging Cradle(PSU Only) (PN#5000-900133G); ■ 4-slot battery charger(PSU Only) (PN#5100-900037G); ■ Power supply for Multi-Slot Cradle (PN#1010-900068G); ■ 3-Pin Power Cord (UK) PN#1550-602689G; ■ 3-Pin Power Cord(EU) PN#1550-602333G; ■ 3-Pin Power Cord(US) PN#1010-601551G; ■ EA660 docking station (PSU Only) (PN#5000-900142G); ■ 5V/6A Power supply for Docking station (PN#1010-900043G); ■ Vehicle cradle (PN#5000-66C0001G) |
|---|
| Conținutul pachetului |
|---|
| The standard package contents | ■ EA660 Terminal; ■ Battery; ■ USB 3.0 Cable (Type C); ■ Adaptor (US or EU plug);; (*Not available in EU) |
|---|
| The basic package contents | ■ EA660 Terminal; ■ Battery; ■ USB 3.0 Cable (Type C) |
|---|
| Certificări |
|---|
| Regulatory Approvals | CE, UKCA, FCC, IC, NCC, VCCI, TELEC, JATE, CCC, SRRC, NAL, RoHS, BQB, N-Mark |
|---|
| Garanție |
|---|
| Hardware Warranty | 12 months |
|---|
| Statement | This product is warranted against defects in workmanship and materials for a period of twelve months from the date of shipment. Accessories are warranted for three months to one year. Our different regions have varying warranty terms, and offer extended and comprehensive warranties, so please contact your local representative for more information. |
|---|
